IP67 Dynamic Water Proof Industrial Metal Numeric Keypad 16 keys Vandal Proof
MODEL NO.: K-TEK-B120KP-BT-DWP
DESCRIPTION: 16 keys compact format IP67 dynamic vandal proof Stainless Steel industrial numeric keypad with
industrial metal dome PCB electronics controller shielded & protected by stainless steel housing, industrial metal dome
PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and
accurate data input, top stainless steel plate with sealing gasket for easy & tight sealing and mounting to enclosure or
panel, with threaded bolts for top panel mounting solution. High quality durable black titanium electroplated on the top
stainless steel plate. Which is good for outdoor application with direct rain and very harsh environments with humidity,
much dynamic water, oil, dirt, salt mist etc, direct drain pipe is optional, no rust risk and anti-salt spray corrosion.
DIMENSIONS: 120.0mm × 98.0mm (Front Panel)
This Keypad is mainly targeted for use for unsupervised or semi-supervised positions of varied access applications,
internet terminals and information kiosks at universities, shopping malls, hotels, banks, airports, railway-stations
and other public areas, ticket vending machines, gas stations, cash machines (ATMs/CDM), Internet public phones etc.
- Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design,
functionality, longevity and high protection level.
- Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof
especially under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
- Waterproof execution according to IP67 protection from top panel, top stainless steel plate with flat keyboard
surface for easy cleaning, threaded bolts & sealing gasket for easy tightly mounting to enclosure or panel.
-An excellent tactile feel with short stroke switches and allow users to achieve stable and accurate data input,
with firm tactile perception for comfortable operation
- Key-tops are laser-etched in legends and characters for easy readability, long life to prevent lettering rub-off.
- Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced
removing key covers.
-Ease of customizing with multiple languages, to accommodate foreign or custom variants.
-Complete electronic modules including controller in close consultation with our customers are available.
Supply Voltage: +5V DC +/-5%
Current Rating: appr. 30mA
EMC Standard: EN 55032:2015 EN 55035:2017
Lifespan > 5 years
Switch Contact Material: Gold-on-Gold key switch technology PCB.
Interface: PS2, USB, RS232, RS485 available
OS: All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed)
Standard PS2/USB keyboard interface.
16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, Cancel, Clear, Enter, backup key 3, 4 x 4 scanning code
Standard RS232 serial interface.
Communication velocity: 9600bps.
Data format: N, 8, 1.
16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, Cancel, Clear, Enter, backup key 3, 4 x 4 scanning code.
Actuator/keys: 16 keys, 1.50mm thickness super quality SUS304 brushed stainless steel flat key.
Key top style: Non-protuberant rectangular keys, laser engraved & etched legends & raised braille on keys
Key Size: 14.0mm x 14.0mm for normal keys, 14.0mm x 28.0mm for function keys
Key travel: 0.45mm
Actuation Force: 3.2N+/-0.1N for key 14.0mm x 14.0mm (pressure point) 4.0N+/-0.1N for key 14.0mm x
28.0mm (pressure point)
Switch life: more than 1 million of operations.
Front Plate: 1.5mm thickness super quality brushed stainless steel
Back Plate: 1.5mm thickness super quality stainless steel
Dimensions: 120.0mm x 98.0mm (L x W )
Operating temperature:-20oC to +60oC
Storage temperature: -30oC to +70oC
Operating RH: 30-90%
Atmospheric pressure: 60-106Kpa.
Saline mist: 96 hours, IEC 60512-6
Damp heat test at + 40oC: 21 days, IEC 60512-6
Dry heat test at + 85oC: 10 days, IEC 60512-6
RoHS Compliant, CE and FCC, ESD
Protection Level: IP67(front panel)
Vandal resistant IK09
Key Lifespan > 1 million actuations
MTBF > 20000H
MTTR < 30min
