IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor

IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor
IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor

Large Image :  IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor

Product Details:
Place of Origin: Shenzhen, China
Brand Name: IKB-MKB
Certification: CE, FCC, ROHS, IP65, IP68, ISO 9001-2015
Model Number: K-TEK-M315TP-FN-BL-NV-151B
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: To be quoted
Packaging Details: Each keyboard to one box, several boxes to one carton.
Delivery Time: ASAP Within 2 weeks upon payment confirmed
Payment Terms: Full payment in advance, Western Union, T/T, Paypal
Supply Ability: 3000psc/month

IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor

Description
Actuator/keys: 89 Keys (including 2 Mouse Buttons) Key Travel: 1.50mm±0.10mm
Actuation Force: 1.5N±0.2N (pressure Point ) Protection Level: IP65 Dynamic (front Panel)
Key Lifespan: >5 Million Actuations G.W.: 0.80KGs
Name: Laptop Keyboard
High Light:

Stainless Steel Metal Joystick Keyboard

,

Trackball Mouse Metal Joystick Keyboard

,

1200 DPI Vandal Proof Keyboard


Rugged Laptop Keyboard With Touchpad


DESCRIPTION: 89 keys IP65 dynamic sealed and durable embedded silicone rubber rugged keyboard integrated with sealed tough touchpad for fast cursor position, with built-in military grade PCB, 12 function keys on top line for easy operation, with carbon-on-gold key switch technology with key stroke (1.50±0.10mm) with extremely good tactile feeling for fast and accurate data input without any noise and error output, with durable coating & anti-microbial keyboard surface withstand to most chemicals and liquids under harsh environment, FN + Clean combination key for easy cleaning via lock/disable whole keyboard without needing to take away the keyboard from PC, panel mount with super thin ruggedized aluminum back plate with mounting holes, adjustable white backlight included. Designed to Meet MIL-STD-461G (EMC, EMI, EMS, ESD) and MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity etc.), which can also meet the critical military standards in these 10 aspects: reliability, safety, maintainability, testability, supportability, environmental adaptability, stability, compatibility, consistency, and continuity.

DIMENSIONS : 315.0mm x 108.0mm (L x W)



IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor 0

IP65 Military Grade Rugged Keyboard With Built In Tough Touchpad For Fast Cursor 1



MECHANICAL DATA
Keys 89 keys (including 2 mouse buttons)
Key top style Protuberant rectangular keys with tactile feeling
Key Size 14.4mm x 14.9mm for normal keys, 25.9mm x 14.9mm for enter key and 69.6mm x 14.9mm for space bar key
Key travel 1.50mm±0.10mm
Actuation Force 1.5N±0.2N (pressure point )
Switch life more than 5 million of operations
G.W. 0.80KGs
ELECTRICAL DATA
Supply Voltage DC +5V±5%
Current Rating 30mA when backlight is off, 300mA with backlight on
Meet MIL-STD-461G (EMC, EMI, EMS, ESD):
1 CE101 25Hz - 10kHz Conducted Emissions, Audio Frequency Currents, Power leads
2 CE102 10kHz -10MHz Conducted Emissions, Radio Frequency Potentials, Power leads
3 CS101 25Hz - 150kHz Conducted Susceptibility, Power Leads
4 CS106 Conducted Susceptibility, Transients, Power Leads
5 CS112 Electrostatic Discharge Susceptibility
6 CS114 4kHz -400MHz Conducted Susceptibility, Bulk Cable injection
7 CS115 Conducted Susceptibility, Bulk Cable injection, Impulse Excitation
8 CS116 10kHz - 100MHz Conducted Susceptibility, Damped Sinusoidal Transients, Cables and Power Leads
9 RE101 25Hz -100kHz Radiated Emissions, Magnetic Field
10 RE102 10kHz - 18GHz Radiated Emissions, Electric Field
11 RS101 25HZ - 100kHz Radiated Susceptibility, Magnetic Field
12 RS103 10kHz - 40GHz Radiated Susceptibility, Electric Field
MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity etc.)
Lifespan > 5 years
Switch Contact Material military PCB with carbon-on-gold key switch technology
Interface USB, other interfaces can be customized.
OS All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed).
ENVIRONMENTAL ADAPTABILITY
Operating temperature -40℃ to +75℃
Storage temperature -45℃ to +85℃
Operating RH 3%~95%
Atmospheric pressure 60-106Kpa
Saline mist 96 hours, IEC 60512-6
Damp heat test at +40℃ 21 days, IEC 60512-6
Dry heat test at +85℃ 10 days, IEC 60512-6
RELIABILITY
RoHS compliant, CE and FCC certified, MIL-STD-461G (EMC, EMI, EMS, ESD) and MIL-STD-810F (wide temperature, shock, salt mist, vibration, fungus, humidity etc.)
Protection Level IP65 dynamic (front panel)
Key Lifespan >5 million actuations
MTBF >20000H
MTTR <30min
APPLICATIONS Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station etc.
