Product Details:
|
| Application: | Military/industrial/marine | Material: | Silicone Rubber |
|---|---|---|---|
| Dimensions: | 206.6mm X 182.0mm X 21.5mm (L X W X H) | Backlight: | Red |
| Color: | Black | Washable: | Yes |
| Key: | 83 Keys + 2 Mouse Buttons | Qty: | 1 Pieces |
| Name: | Military EMC Keyboard | ||
| High Light: | IP68 Silicone Industrial Keyboard,FCC Silicone Industrial Keyboard,IP68 Lighted Desktop Keyboard |
||
IP68 Silicone Industrial Keyboard With Force Sensing Resistor Pointing Device
DESCRIPTION: 83 keys IP68 dynamic sealed and ruggedized silicone rubber military keyboard with a Force Sensing Resistor pointing device for fast and accurate cursor position, 12 FN keys (F1, F2...F11, F12) are on top line for easy operation, with carbon-on-gold key switch technology with long stroke (1.50mm) with extremely good tactile feeling for fast and accurate data input without any noise, with durable coating & antimicrobial keyboard surface withstand to most chemicals and liquids under harsh environment, FN + CLEAN combination key to lock/disable the keyboard for easy cleaning without needing to take away the keyboard from PC, standard alone movable desk top version with fully stainless steel metal housing, with red backlight included. Military level.
MILITARY KEYBOARD Dimensions: 206.6mm x 182.0mm x 21.5mm (L x W x H)
| MECHANICAL DATA | |
| Keys | 83 keys + 2 mouse buttons |
| Key top style | Protuberant rectangular keys with tactile feeling |
| Key Size | 14.00mm x 13.80mm for normal keys |
| Key travel | 1.50mm±0.1mm |
| Actuation Force | 1.5N±0.2N (pressure point ) |
| Switch life | more than 5 million of operations |
| G.W. | 1.80KGs |
| ELECTRICAL DATA | |
| Supply Voltage | DC +5V±5% |
| Current Rating | 50mA when backlight is off, 300mA with backlight on |
| EMC Standard | EN 55032:2015 EN 55035:2017 |
| Lifespan | > 5 years |
| Switch Contact Material | Carbon-on-Gold key switch technology |
| Interface | PS2, USB available |
| Cable lengh | Standard 2.0m, customized length available |
| OS | All Windows, Linux, Unix, Mac OSX, Vxworks, Android, (U-cos--To be confirmed). |
| ENVIRONMENTAL ADAPTABILITY | |
| Operating temperature | -25℃ to +60℃ |
| Storage temperature | -40℃ to +70℃ |
| Operating RH | 100% |
| Atmospheric pressure | 60-106Kpa |
| Saline mist | 96 hours, IEC 60512-6 |
| Damp heat test at +40℃ | 21 days, IEC 60512-6 |
| Dry heat test at +85℃ | 10 days, IEC 60512-6 |
| SILICONE INDUSTRIAL KEYBOARD RELIABILITY | |
| RoHS compliant, CE and FCC certified | |
| Protection Level | IP68 |
| Key Lifespan | >5 million actuations |
| MTBF | >20000H |
| MTTR | <30min |
| APPLICATIONS | Vehicle, aerospace, naval, defense, maritime, Radar, console, portable rugged laptop, UAV ground station etc. |
